ALL OUR 2018 USED SLEDS ARE NOW IN STOCK
ALL
PRODUCT IS A+ QUALITY USED
LOCATED 2000 MAIN ST E,NORTH BAY,ON
A superior performer on trail, its longer track enables you to
bridge bumps for a smooth ride and head off trail. An impressive feature
set includes three Rotax engine choices.
Feature Highlights
RAS™ 2 Front suspension: A taller ski spindle, refined geometry and
lighter components sharpen the sled’s already precise handling,
especially in extreme conditions.
RF D.E.S.S.™ Key: D.E.S.S.™
security system on most models uses Radio Frequency technology for peace
of mind. The ball-and-socket design ensures a solid connection in all
conditions.
rMotion™ suspension: Sets new standards in comfort,
capability and adjustability.
LinQ™ cargo system (option): Our cargo
attachment system is the hassle-free way to connect cargo bags or a fuel
caddy to your sled in seconds.
Analog gauge with display
Package
Highlights
RAS™ 2 front suspension
REV-XS™ platform
rMotion™
rear suspension
15 x 137 x 1.25 in. RipSaw® track
HPG™ Plus
aluminum front shocks
Pilot™ 5.7 skis
Brembo brake with braided
stainless-steel brake line
Analog gauge with display
Electric fuel
gauge
15 in. / 38 cm windshield with integrated hand wind deflectors
Painted tunnel
RF D.E.S.S.™ key
REV-XP™ X seat with 5 L / 1.3 US
gal of storage
Extra Highlights
Mechanical reverse
Reversible
throttle lever (thumb or finger activated)
iTC™ Engine mapping modes
(Standard, Sport or ECO®)
Engine oil cooler
Learning Key included
Extended heat exchanger for better cooling capacity
Engine
Rotax®
Engine: 900 ACE
Engine details: Liquid-cooled, four-stroke D.O.H.C.,
dry sump
Cylinders: 3
Displacement: 899 cc / 54.9 in.³
Bore: 74
mm / 2.9 in.
Stroke: 69.7 mm / 2.7 in.
Maximum engine speed: 7,250
RPM
Carburation: EFI
Recommended fuel type: Regular unleaded
Minimum octane: 87
Fuel tank: 40 L / 10.6 US gal
Oil tank
capacity: 3.3 L / 3.5 qt
Powertrain
Drive clutch type: eDrive™ 2
Driven clutch type: QRS (short shaft)
Engagement: 2,200 RPM
Small
sprocket number of teeth: 24
Large sprocket number of teeth: 49
Drive sprocket number of teeth: 8
Drive sprocket diameter: 183 mm /
7.2 in.
Brake system: Brembo brake with braided stainless-steel brake
line
Dry Weight
Dry Weight: 228 kg / 503 lb
Color
Black
Dimensions
Vehicle overall length: 3,110 mm / 122.4 in.
Vehicle
overall width: 1,217 mm / 47.9 in.
Vehicle overall height: 1,210 mm /
47.6 in.
Ski stance: 1,077 mm / 42.4 in.
Ski overall length: 1,066
mm / 42 in.
Track nominal width: 381 mm / 15 in.
Track nominal
length: 3,487 mm / 137 in.
Track profile height: 31.8 mm / 1.25 in.
RipSaw®
Suspension
Front suspension: RAS™ 2
Front shock: HPG™
Plus
Front suspension max. travel: 220 mm / 8.7 in.
Rear
suspension: rMotion™
Center shock: HPG™
Rear shock: HPG™
Rear
suspension max. travel: 270 mm / 10.6 in.
Features
Frame: REV-XS™
Skis: Pilot™ 5.7
Seating: REV-XP™ X with storage
Handlebar:
Aluminum with J-hooks
Riser block height: 115 mm / 4.5 in.
Starter: Electric
Reverse: Mechanical
Heated throttle lever:
Standard
Heated grips: Standard
Gauge: Analog with display
Mirrors: Optional
Windshield: 375 mm / 15 in.
Runner: Square 5/16
Carbide configuration: 102 mm / 4 in. at 90°
Hitch: Optional
Gauge
Features
Speedometer: Standard
Tachometer: Standard
Fuel:
Standard
Engine temperature: Optional
While every reasonable effort is made to ensure the accuracy of this data, we
are not responsible for any errors or omissions contained in these pages. Please
verify any information in question with a representative of ATV WAREHOUSE
